Summary

On 24 February 2026, a configuration change to the BIRD2 routing daemon on our primary BGP router caused a mass re-export of approximately 1.1 million IPv4 routes and 250,000 IPv6 routes to the Linux kernel. The re-export consumed BIRD's single processing thread for an extended period, preventing it from responding to BGP keepalive messages from peers. This resulted in widespread session timeouts across our peering and transit infrastructure, with established session count dropping from approximately 60 to fewer than 20 at the lowest point.

All sessions recovered automatically once the change was reverted. No customer traffic was permanently lost, though customers may have experienced degraded routing and increased latency during the incident window.

Background

Optua operates AS202076 from a virtual private server hosted by one of our partners in Glasgow. The VPS runs BIRD2 as its BGP daemon and carries a full routing table from multiple transit providers and Internet Exchange Points including LONAP, LINX LON1, LINX LON2, and BGP.Exchange. At the time of the incident, the router was handling over 1.1 million IPv4 prefixes and approximately 250,000 IPv6 prefixes across 60 BGP sessions.

The change was part of a planned maintenance task to configure a RIPE Atlas software probe on the network. The probe needed to source its traffic from Optua's own IP address space rather than from our partners' infrastructure addresses. To achieve this, a kernel preferred source attribute (krt_prefsrc) was added to the BIRD kernel protocol export filter, which instructs the Linux kernel to stamp a specific source IP on every route in the routing table.

Root cause

BIRD2 is single-threaded for route processing. When the kernel protocol export filter was changed from "export all" to an export filter containing a krt_prefsrc directive, BIRD did not apply this change incrementally. Instead, it triggered a complete re-export of every route in the routing table to the Linux kernel. This meant approximately 1.35 million routes were queued for update simultaneously.

While BIRD was processing this queue, it could not service any other tasks, including responding to BGP keepalive messages from peers. Most BGP sessions are configured with hold timers between 90 and 180 seconds. As the re-export took longer than these timers to complete, remote peers began closing sessions due to hold timer expiry.

Each closed session then generated additional work for BIRD in the form of route withdrawals and, once the peer attempted to reconnect, full session re-establishment and route re-advertisement. This created a cascading effect where the initial churn generated further churn, prolonging the recovery time.

Timeline (all times UTC)

00:59 - Configuration change applied via birdc configure. The krt_prefsrc directive was added to both the IPv4 and IPv6 kernel protocol export filters simultaneously.

01:00 - BIRD begins re-exporting the full routing table to the Linux kernel. The birdc command line interface becomes sluggish.

01:05 - First BGP sessions begin timing out. Grafana monitoring shows established session count declining.

01:10 - Session count drops below 40. Prefix counts on IXP route server sessions show significant reductions.

01:15 - Session count drops below 20. Decision made to revert the change immediately.

01:17 - Configuration reverted to the original kernel protocol export. birdc configure applied.

01:20 - BIRD begins recovering. Sessions start re-establishing as the re-export queue clears and BIRD resumes normal keepalive processing.

01:30 - Majority of sessions re-established. Prefix counts returning to normal.

01:35 - All sessions confirmed Established. Full prefix counts restored across all peers.

01:38 - Status page updated to reflect recovery. Decision made to reattempt the change using a safer approach.

01:45 - IPv6 kernel protocol updated with krt_prefsrc in isolation. At approximately 250,000 routes, the re-export completed quickly with no session loss.

02:00 - IPv4 kernel protocol updated with krt_prefsrc separately. Some brief session disruption during re-export of 1.1 million routes, but all sessions recovered within minutes.

02:12 - RIPE Atlas probe confirmed connected under AS202076 with correct source addressing on both IPv4 and IPv6.

02:15 - Incident declared resolved.

Impact

Approximately 40 BGP sessions were lost during the peak of the incident. This included sessions with transit providers, IXP route servers, and bilateral peers at LONAP, LINX, and BGP.Exchange. During this window, traffic to and from AS202076 would have been routed suboptimally or, in some cases, may have been unreachable via certain paths. Customers relying on peering routes for low-latency connectivity would have experienced increased latency or brief interruptions.

No data was lost. No configuration was permanently altered. All sessions recovered automatically without manual intervention beyond the revert.

Contributing Factors

The change was applied to both IPv4 and IPv6 kernel protocols simultaneously, maximising the volume of routes requiring re-export.
The VPS carries a full BGP routing table from multiple sources, meaning the re-export volume was in excess of 1.35 million routes combined.
BIRD2's single-threaded architecture means any long-running operation blocks all other processing, including session maintenance.
No pre-change assessment was made of the likely duration of the re-export, or its impact on session hold timers.
The change was performed on a production router carrying live traffic without a maintenance window or pre-staged rollback plan.

Corrective Actions

The krt_prefsrc change has been successfully applied to both IPv4 and IPv6 kernel protocols by performing them sequentially rather than simultaneously, reducing the per-operation churn and allowing sessions to remain stable.

The RIPE Atlas software probe is now operational under AS202076 and sourcing traffic from Optua's own address space on both address families.

A systemd service has been created to ensure the required network interfaces and IP assignments persist across reboots.

Planned actions

We are in the process of migrating our BGP infrastructure from the current virtualised server environment to a dedicated hardware router. This will provide a purpose-built routing platform with multi-threaded BGP processing, hardware-accelerated forwarding, and dedicated memory for the routing table. This migration will eliminate the class of issue experienced during this incident, as dedicated routing hardware handles kernel route table updates fundamentally differently from a Linux VPS running BIRD in userspace.

Hold timers on all BGP sessions will be reviewed and, where appropriate, increased to provide additional headroom during future maintenance operations.

A formal change management process will be introduced for any modifications to the kernel protocol configuration, including mandatory pre-change impact assessment and a documented rollback procedure.

Future maintenance involving bulk route table operations will be performed during a scheduled maintenance window with advance notice to affected peers.

Lessons Learned

The core lesson from this incident is that on a full-table BGP router running BIRD2 on Linux, any change to the kernel export filter is not an incremental operation. It triggers a complete re-export of the entire routing table. On a router carrying over a million prefixes, this is a significant event that can block BIRD's processing thread long enough to cause widespread session loss.

The secondary lesson is that applying changes to IPv4 and IPv6 simultaneously doubles the workload. Performing them sequentially, starting with the smaller table, allows the operator to gauge the impact before committing to the larger and riskier operation.

Finally, this incident reinforces the case for migrating to dedicated routing hardware, where the control plane and forwarding plane are separated and route table updates do not compete with session maintenance for processing time.
